THE BENCHMARK HARDCORE HARDTAIL - GOES UP ANOTHER NOTCH

When it comes to swift but gnarly hardtails the Orange Crush line-up is the benchmark others aim for. The original aluminium hardcore hardtail gets a 2022 tune-up to keep it ahead of the game. The frame has gone through a couple of geometry adjustments and a few construction refinements. First, and most obvious, is the new one-piece chainstay yoke. It is forged for maximum toughness and provides improved lateral rigidity for pedalling performance, and leaves plenty of clearance for larger tyres, while giving the chainring plenty of space to breathe in muddy conditions.

The new frame features a tapered headtube, giving us more weld area to add strength and provide more support for the lower headset bearing. Where others skimp on the bottom bracket shell, we belive the extra strength benefits of a 73mm width in this area pays back big-time of a hardtail that gets the thrashing we know a typical Crush will get.

GENRE DEFINING GEOMETRY

For the new frame's geometry we've pulled things forward (seat-tube 75.5°) to make the ride a little more aggressive, slackened the front-end (headangle 64.5° and 63.5° on the Crush 27.5)and stretched the wheelbase for stability, while keeping the reach roomy (480mm on a size Large). Coupled with the reduced offset forks we now spec, the rider's weight pitches perfectly in the attack position for more balanced weight distribution and let the front wheel find grip and prevent front end wash-out. That's not happening here - getting that front tyre biting in and letting the bike flow is what the Crush is all about.

There are plenty more details to admire on the new frame; a strong and secure bolt-through rear rear axle, new cnc-ed cable grommets that not only look great, but keep things tight when everything else around you is getting loose. Some neat new gusseting around the seat-stays add strength and confidence.

This is one of the most significant updates to the Crush hardtail platform in years, in testing we've fallen in love with it all over again. It's not all about bouncy bikes, sometimes you just have to take the fight to the trail, and the new Crush takes it to another level.

WHY THE CRUSH 29?

F: 140MM | W: 29

• Brand New Frame designed in Britain
• 5 year frame warranty with Limited Lifetime Crash Replacement
• Custom butted 6061-T6 aluminium frame
• Frame geometry for 140mm travel reduced offset fork
• Bolt through 12 x 148 hub spacing
• New CNC Chainstay Yoke design gives clearance and strength
• Tyre clearance for 29 2.6 tyres
• 73mm BB Shell with ISCG 05 tabs
• New Tapered Head tube ZS44/ZS56
• CNC Cable grommets
• Minimal design cable & hose guides
• Available in 3 specs: Crush, Crush Comp and Crush Pro

Colour: Candy Red

Decals: Black/Silver Decals

FRAME AND FORK

6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 29.

Swingarm: Bolt Type Allen Key Head (Boost 148mm Hub)

Rear Shock: N/A

Headset: FPD 44mm / 56mm zerostack

Fork: RockShox Lyrik Select 140mm 29

DRIVETRAIN

Shifters: SRAM SX Eagle

Cassette: SRAM SX 1210 11-50T Eagle

Chain Device: Not Included

Bottom Bracket: SRAM DUB

Crankset: SRAM SX Eagle 32t

Rear Mech: SRAM SX Eagle 12spd

Chain: SRAM SX Eagle

WHEEL AND TYRES

Wheelset: WTB ST i30 on Strange 29

Tyres: Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 29

BRAKING

Brakes: SRAM Guide T 200/180

FINISHING KIT

Seatpost: KS Ragei 150/170mm Drop

Seat Clamp: Strange Bolted

Stem: Burgtec Enduro Black 42.5mm

Saddle: WTB Silverado SL

Handlebars: RaceFace Chester 780mm M35

Grips: Strange Grappler Lock-On

CRUSH GEOMETRY

6061-T6 Custom Butted OS Aluminium Tube
Frame Size	M	L	XL
Seat Tube Length	17"	18"	20"
A. Head Angle	64.5°	64.5°	64.5°
B. Seat Angle	75.5°	75.5°	75.5°
C. Top Tube	643	658	675
D. Top Tube (effective)	630	652	675
E. BB Height (from ground)	310	310	310
E. BB height (axle DIFF)	-68	-68	-68
F. Chainstay	445	445	445
G. Headtube	120	130	140
H. Wheel base	1229	2154	1278
J. Reach	460	480	500
K. Stack	657	666	675
O. Fork Offset	44	44	44
Standover	691	708	749
Stem length	50	50	50
Unless otherwise indicated all measurements are in mm. Frame angles are measured static, without rider sag. Bottom bracket height from ground is with 756 mm Ø tyre.
