2027 Mondraker Anark R MTB
Regular price £3,999.00The all-new ANARK enters the Mondraker gravity line-up for 2026, designed with a fun-first approach and slides straight into the bike park and freeride category.
ANARK brings modern geometry, kinematics and performance to the wilder side of riding. It’s about the most fun you can have on a mountain bike. We’re talking face aching grins; sock marks on dusty shins and that urge for one last party train. ANARK is all about getting in that bike park shred state.
Slappin’ turns and spraying dirt.
Bike parks and trails designed for maximum fun are on the up, and the new ANARK is the bike to find your shred state on. It builds on the success of the Foxy platform and pulls from the MFR race development programme to offer our most exciting long travel gravity rig to date.
STEALTH ALLOY EVO
Built for durability and tuned with smart geo adjust, ANARK is ready to stand out at any bike park, delivering pure downhill-focused performance.
Designed for bike park fanatics and freeride souls, delivering downhill strength and resilience with the agility to adapt to any challenge, trick or descent, thanks to refined geometry.
Frame
Anark 6061 Alloy Stealth Evo, Mullet, hydroformed tubing, Updated Zero Suspension System, 170mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, UDH, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, Max. capacity sealed bearings, ISCG 05
Sizes
S: 440mm / M: 460mm / ML: 480mm / L: 500mm / XL: 520mm
Rear shock
RockShox Vivid Coil Select+, 205x65mm. Settings: external bottom out, low-speed rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings
Shock settings
C26 compression, R23 rebound. Spring rate: S size 350 lbs, M size 400 lbs, ML size 450 lbs, L size 500 lbs, XL size 500 lbs
Fork
RockShox ZEB Base Rush RC 29, 180mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: low-speed compression, Extl rebound, air preload
Headset
Onoff custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Stem
Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore
Handlebar
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost
X-Fusion Manic diameter 31.6mm,1X Remote lever, S size: 361x125mm, M size: 425x150mm), ML size: 469x170mm, L size: 521x190mm, XL size: 531x200
Saddle
Ergon Enduro SPS20
Front brake
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever
Sram DB8 Stealth, tool reach adjust, lever pivot bushings
Rims
WTB Sportterra Tough,6061 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
Spokes
WTB Straight gauge spokes & black brass locking nipples
Front hub
WTB Frequenzy Sport Boost 15x110mm, fully machined aluminum, IS 6 bolts
Rear hub
WTB Frequenzy Sport Boost 12x148mm, fully machined aluminum, IS 6 bolts, HG freehub
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DH casing, 60x2TPI, folding bead
Rear tire
Maxxis Minion DHR II 27''5x2.5 WT, tubeless ready, 3C Maxx Terra compound, DH protection, 60x2TPI, folding bead
Crankset
Sram 70 T-Type, Boost, DUB axle, Direct mount chain ring, S size: 165mm M size: 165mm ML size: 165mm L size: 170mm XL size: 170mm, CL 55
Rings
32T, Alloy, T-type
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram 70 T-Type, 12s Flattop, PowerLock
Rear derrailleur
Sram 70 Eagle, T-Type, 12s
Shift levers
Sram Trigger 70, 12s, T-Type Actuation
Casette
Sram XS-1270, 10-52T, 12s
Weight
17,8 kg
Geometry
|
Frame size
|
S | M | M/L | L | ||
|---|---|---|---|---|---|---|
| A | Seattube length | 380 mm | 410 mm | 435 mm | 460 mm | 490 mm |
| B | Toptube length | 583 mm | 603 mm | 625 mm | 647 mm | 669 mm |
| C | Bottom bracket drop | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm |
| D | Bottom bracket height | 346 mm | 346 mm | 346 mm | 346 mm | 346 mm |
| E | Chainstay length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| F | Seat tube angle | 74° | 74° | 74° | 74° | 74° |
| G | Effective seattube angle | 77.5° | 77.5° | 77.5° | 77.5° | 77.5° |
| H | Headtube angle | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| I | Fork Offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| J | Wheelbase | 1241 mm | 1261 mm | 1285 mm | 1310 mm | 1334 mm |
| K | Headtube length | 110 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| L | Reach | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm |
| M | Stack | 644 mm | 644 mm | 653 mm | 662 mm | 671 mm |
2026 Mondraker Crafty Unlimited Icon EMTB Limited Edition
Regular price £11,699.00 Sale price £8,749.00 Save £2,950.00
It is rare for a bike to transcend its role as simply a bike and become something much greater. A symbol. A way of understanding e-mtb. An icon.
Crafty was born ten years ago, coinciding with the arrival of the first generation of the Bosch Performance Line CX: the first motor created specifically for e-mtb. It was then that we saw the opportunity to develop an electric bike designed from its core for mountain biking, our specialty.
The most versatile. The most complete. The bike capable of climbing the most technical trails and riding with confidence and stability on the fastest and most demanding descents. Mondraker’s Zero Suspension system and Forward Geometry, optimised for the Crafty platform are combined to maximise traction, stability and control on any terrain.
To mark its tenth anniversary, we present the ultimate expression of the Crafty. A limited and exclusive edition created to celebrate its evolution. A unique and one-of-a-kind Crafty. The Crafty Unlimited ICON.
DRIVEN BY BOSCH. DEFINED BY MONDRAKER.
Numbers on their own mean nothing.
But sometimes, three numbers can tell a story.
600% means boosting your power even further. The new update gives you 600% of max pedal assistance. Or, to put it another way: your muscle power, times 6.
120 Nm means breaking another barrier. Reaching a new torque figure that puts the Crafty at the very top. Greater acceleration for those highly technical climbs, even at low cadence.
10 years means a decade leading the e-mtb market. Ten years perfecting a bike that has become the benchmark.
Three numbers that mark the Crafty’s new path. And that make this Unlimited edition the most special in its entire history.
Components
Frame
Crafty Stealth Air full Carbon, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock
Öhlins TTX22M.2 185x55mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings
Shock settings
C20 compression, R40 rebound. Spring rate: S size 411 lbs, M size 457 lbs, size ML 502 lbs, L size 548 lbs, XL size 605 lbs
Fork
Öhlins RXF 38 M.3 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Stem
Onoff S9 30mm 0º, Full CNC, 31.8mm barbore
Handlebar
Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost
RockShox Reverb Stealth AXS, diameter 31.6mm S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm
Saddle
Fizik Vento Argo 00 Carbon 150mm
Front brake
Trickstuff Maxima, 7075 T6 CNC alloy 4 piston caliper, 203mm IS 6 bolts one-piece rotor
Rear brake
Trickstuff Maxima, 7075 T6 CNC alloy 4 piston caliper, 203mm IS 6 bolts one-piece rotor
Brake lever
Trickstuff Maxima, 7075 T6 CNC alloy, lever pivot bearings, tools-free reach adjust, Kevlar hose
Rims
DT Swiss HXC1200 Carbon Spline 29, 30mm internal width, hookless, tubeless ready, 28 spokes
Spokes
DT complite® Hybrid t-head
Front hub
DT 180, Boost 15x110mm, IS 6 bolts
Rear hub
DT 180, Boost 12x148mm, Ratchet EXP OS 42 system, IS 6 bolts, XD freehub
Front tire
Maxxis Minion DHF 29x2.5, tubeless ready, 3C Maxx Grip, EXO+ Protection, 600TPI, folding bead
Rear tire
Maxxis Minion DHR II 29x2.5 tubeless ready, 3C Maxx Terra, EXO+ Protection, 60TPI, folding bead
Crankset
E.13 Helix Race Carbon E*Spec Plus, All sizes: 160mm
Rings
Sram XX Eagle 34T T-Type, direct mount, steel, CL55
Chain
Sram XX Eagle T-Type, 12s, Powerlock
Front derrailleur
Sram XX Eagle AXS, T-Type, 12s
Rear derrailleur
Sram Eagle AXS Pod Rocker, 12s
Casette
Sram XS-1295, 10-52T, T-Type, 12s
Display
Kiox 400 / Bosch Mini Remote
Motor
Bosch Performance Line CX-R(25Km/h) SMART SYSTEM (BDU386Y)
Battery
Bosch Powertube 800Wh
Geometry
|
Frame size
|
S [Std/Low] | M [Std/Low] | M/L [Std/Low] | L [Std/Low] | ||
|---|---|---|---|---|---|---|
| A | Seattube length | 380 mm | 410 mm | 435 mm | 460 mm | 490 mm |
| B | Toptube length | 581 mm/582 mm | 596 mm/597 mm | 618 mm/619 mm | 640 mm/641 mm | 662 mm/663 mm |
| C | Bottom bracket drop | -25 mm/-30 mm | -25 mm/-30 mm | -25 mm/-30 mm | -25 mm/-30 mm | -25 mm/-30 mm |
| D | Bottom bracket height | 350 mm/345 mm | 350 mm/345 mm | 350 mm/345 mm | 350 mm/345 mm | 350 mm/345 mm |
| E | Chainstay length | 455 mm/456 mm | 455 mm/456 mm | 455 mm/456 mm | 465 mm/466 mm | 465 mm/466 mm |
| F | Seat tube angle | 73°/72.65° | 73°/72.65° | 73°/72.65° | 73°/72.65° | 73°/72.65° |
| G | Effective seattube angle | 77.95°/77.6° | 77.95°/77.6° | 77.95°/77.6° | 77.95°/77.6° | 77.95°/77.6° |
| H | Headtube angle | 64.5°/64.15° | 64.5°/64.15° | 64.5°/64.15° | 64.5°/64.15° | 64.5°/64.15° |
| I | Fork Offset | 44 mm | 44 mm | 44 mm/44 mm | 44 mm | 44 mm/44 mm |
| J | Wheelbase | 1240 mm/1241 mm | 1255 mm/1256 mm | 1280 mm/1281 mm | 1314 mm/1315 mm | 1338 mm/1339 mm |
| K | Headtube length | 120 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| L | Reach | 445 mm/441 mm | 460 mm/456 mm | 480 mm/476 mm | 500 mm/496 mm | 520 mm/516 mm |
| M | Stack | 638 mm/641 mm | 638 mm/641 mm | 647 mm/650 mm | 656 mm/659 mm | 665 mm/668 mm |
2026 Mondraker Zendit RR EMTB
Regular price £7,399.00the flagship Mondraker e-MTB that boasts a new level of performance, achieved from the latest frame design and ZERO suspension kinematics, with seamless integration of the powerful new Avinox drive system.
Designed for aggressive riding on the nastiest climbs and descents, ZENDIT is the result of over 11 years of e-MTB development, combined with the no-holds-barred approach to suspension performance from the Mondraker Factory Racing development team.
Zendit was created for those who see the mountains as a challenge, as a place to push the boundaries. A bike with character, energy, and an almost instant response to every challenge. When the slope steepens, the ride gets faster and the terrain becomes unpredictable, everything falls into place. Zendit unleashes its full potential.
Feel free, with a power that’s hard to contain. Turn every ride into an even more intense experience. Because it’s not just about going further, but doing so with the confidence and determination of someone who knows they’re in control, even in the most demanding situations.
STEALTH AIR CARBON THE NEXT EVOLUTION
Rather than adapting an existing platform, the ZENDIT frame was designed to house the most advanced motor system on the market.
This frame is highly advanced in both design and manufacture. For the first time 6-Axis CNC machines are used for frame drilling and finishing in place of hand finished frames.
ZENDIT takes advantage of everything learnt from the MFR DH development team and uses the same pivot system as the new and proven Summum DH frame.
With single-size Enduro Max bearings throughout, maintenance becomes easier and two additional rubber seals help the bearings last longer.
PROPORTION MATTERS
As with other bikes over 150mm of rear wheel travel, ZENDIT comes stock with a mixed wheel configuration - it’s the best overall performance for the aggressive riding. But it can easily rock 29’’ wheels for even more climbing capability!
ZENDIT features proportional chainstay lengths depending on the sizes. S; M and M/L sizes offer the same 450mm chainstay length, whereas the L and XL models are 5mm longer at 455mm. By slightly adjusting pivot placement in all sizes, the same leverage ratio is achieved throughout. So, no matter what size you need, you get the same ride qualities.
Components
Frame
Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock
Fox Float X Factory Kashima Evol LV 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.
Shock settings
CS 30 compression, 1,1 Bleed, RL50 rebound, Rezi B40, LML, standard MCU, 0 volume spacers
Fork
Fox 38 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.
Fork remote
N/A
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, without blocklock.
Stem
Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.
Handlebar
Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size.
Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm).
Saddle
Ergon SM10 E-Mountain Black.
Front brake
Sram Maven Base, 18-millimeter 4 piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads.
Rear brake
Sram Maven Base, 18-millimeter 4 piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads.
Brake lever
Sram Maven Base stealth lever architecture, tools-free reach adjust
Rims
DT Swiss Hybrid H 1900 SPLINE, aluminum, hooked / crotchet tubeless TC, 30mm internal width, tubeless ready, 28 spokes.
Spokes
DT Hybrid I Straightpull, w/DT ProLock Squorx ProHead aluminum nipples, Three-cross (1:1) pattern.
Front hub
DT Swiss 370, 15x110mm Boost, Disc IS (6-bolt).
Rear hub
DT Swiss 370, 12x148mm Boost, Disc IS (6-bolt), Sram XD Steel (SSRAM) freehub body, Ratchet LN 18 freehub system.
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead
Rear tire
Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead
Crankset
e*thirteen Helix Core e*spec alloy. All sizes: 155mm
Rings
Sram XX Eagle 36T T-Type, 104BCD, steel, CL55
Bottom bracket
N/A
Pedals
N/A
Chain
Sram GX Eagle T-Type, 12s, w/Powerlock
Front derrailleur
N/A
Rear derrailleur
Sram S1000 Eagle AXS, T-Type, 12s
Shift levers
Sram Eagle AXS Pod Controller w/discrete clamp, 12s
Casette
Sram XS 1270, 10-52T, T-Type, 12s
Derailleur hanger
Not included - UDH compatible
Weight
22.8 Kg
Display
Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
Motor
Avinox Drive Unit
Battery
Avinox 800Wh Battery / Avinox 4A Charger
Geometry
|
Frame size
|
S | M | M/L | L | ||
|---|---|---|---|---|---|---|
| A | Seattube length | 380mm | 410mm | 435mm | 460mm | 490mm |
| B | Toptube length | 586mm | 606mm | 628mm | 650mm | 672mm |
| C | Bottom bracket drop | 6mm | 6mm | 6mm | 6mm | 6mm |
| D | Bottom bracket height | 345mm | 345mm | 345mm | 345mm | 345mm |
| E | Chainstay length | 450mm | 450mm | 450mm | 455mm | 455mm |
| F | Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| G | Effective seattube angle | 77° | 77° | 77° | 77° | 77° |
| H | Headtube angle | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| I | Fork Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
| J | Wheelbase | 1241mm | 1261mm | 1286mm | 1315mm | 1339mm |
| K | Headtube length | 110mm | 110mm | 120mm | 130mm | 140mm |
| L | Reach | 440mm | 460mm | 480mm | 500mm | 520mm |
| M | Stack | 631mm | 631mm | 640mm | 649mm | 658mm |
| N | Stem Length | null | null | null | null | null |
| O | Fork Height | null | null | null | null | null |
