The 2026 Orbea Rise SL H30 540W is a lightweight electric trail mountain bike (e-MTB). Rise is Orbea's lightweight electric mountain bike range, with a natural trail-bike ride feel and motor assistance when you need it. The H30 is built on the aluminium Rise SL Hydro frame and is powered by a Shimano EP600 RS motor with an Orbea Internal 540Wh battery, Shimano Deore M6100 shifting and Shimano MT201 Hydraulic Disc brakes.
Key features
- Shimano EP600 RS Gen2 MC motor (85Nm) with Orbea Internal 540Wh battery, compatible with the optional 252Wh Range Extender
- Orbea Rise SL Hydro aluminium frame, 140mm travel, 29" wheels, Concentric Boost 12x148
- Fox 34 Float AWL Sport 140 Rail fork and Fox Float Performance 2-Pos Evol LV custom tune 210x50mm shock
- Shimano Deore M6100 12-speed drivetrain with Shimano MT201 Hydraulic Disc brakes, 180mm rotors front and rear
Specification
- Frame: Orbea Rise SL Hydro 2025, 140mm travel, 29" wheels, Concentric Boost 12x148
- Fork: Fox 34 Float AWL Sport 140 Rail QR15x110
- Shock: Fox Float Performance 2-Pos Evol LV custom tune 210x50mm
- Motor: Shimano EP600 RS Gen2 MC
- Battery: Orbea Internal 540Wh (Optional 252Wh Range Extender)
- Charger: Orbea 2.Generation eBike Smart charger 42V/2-4A
- Remote: EN600-L
- Headset: Alloy 1-1/2", Black Oxidated Bearing
- Stem: OC Mountain Control MC20, 0º
- Handlebar: OC Mountain Control MC31, Rise20, Width 800
- Brakes: Shimano MT201 Hydraulic Disc w/ Shimano SMRT30 Rotors 180mm front / 180mm rear
- Rear derailleur: Shimano Deore M6100 SGS Shadow Plus
- Shifters: Shimano Deore M6100
- Cassette: Shimano CS-M6100 10-51t 12-Speed
- Chain: Shimano M6100
- Chainguide: Orbea eBike chainguide
- Crank: Shimano Steps EM600
- Chainring: e*thirteen Helix Core e*spec Direct Mount 32T 55mm ChainLine
- Wheels: Alloy, Tubeless, 29", 29c, 32H
- Tyres: Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Addix
- Seatpost: OC Mountain Control MC22, 31.6mm, Dropper
- Seatpost remote: Shimano SL-MT500
- Saddle: Fizik Terra Ridon X5 145mm
- Grips: OC Lock On
Geometry (mm)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Seat Tube (C-T) | 405 | 415 | 430 | 460 |
| Top Tube (EFF) | 568 | 594 | 622 | 651 |
| Head Tube | 95 | 105 | 110 | 120 |
| Chainstay | 440 | 440 | 440 | 440 |
| BB Drop | 37 | 37 | 37 | 37 |
| BB Height | 334 | 334 | 334 | 334 |
| Wheelbase | 1192 | 1220 | 1249 | 1278 |
| Head Angle | 65.5 | 65.5 | 65.5 | 65.5 |
| Seat Angle | 78 | 78 | 78 | 78 |
| Rake | 44 | 44 | 44 | 44 |
| Reach | 440 | 465 | 490 | 515 |
| Stack | 609 | 613 | 623 | 632 |
Geometry figures supplied by Orbea.
Available in sizes S, M, L and XL.
