Our DNA comes from DH racing, there’s no denying it and we’re proud of it. DH is the Formula 1 of mountain biking. It’s where prototypes are put through the wringer, hammered by the tracks and the riders. That’s why at Mondraker we have a top-level international team: the Mondraker Factory Racing, which includes world-class riders such as Dakotah Norton and Ronan Dunne. Our DH bikes will continue to be available as carbon or aluminium framed versions, depending on rider preference.
Components
Technical specs
-
Frame
Summum MX 6061 Alloy Stealth Evo, Mullet, hydroformed tubing, Zero suspension system, 200mm travel, Forward Geometry, alloy upper link with shock eyelet bearings, SuperBoost 12x157mm rear axle, 83mm BSA bottom bracket, MAX. capacity dual row Enduro bearings, HHG internal cable routing, ISCG 05. *Optional Geometry kit
Sizes
S / M / L / XL MX
-
Rear shock
Fox DHX2 Factory Kashima, 225x70mm. Settings: high and low-speed compression, high and low-speed rebound, spring preload. Super light steel (SLS) spring. Trunnion top mount, 30x8mm bottom bushings
Shock settings
CX004 compression, ECR012 rebound Rezi BX001. Spring rate: S size 400 lbs, M size 450 lbs, L size 500 lbs, XL size 500 lbs
-
Fork
Fox 40 29 Float FIT GRIP X2 EVOL Factory Kashima, 203mm, air spring, 1-1/8” steerer tube, 20x110mm axle, offset 52mm. Settings: high and low-speed compression, high and low-speed rebound, air preload
Headset
Onoff ZS56/ZS56, 1-1/8", 1-1/8" steerer tube, 42x30x7x45ºx45º ACB sealed bearings, geometry kit cups, external diameter 62mm
-
Stem
Onoff S9 DH CNC Integrated, 45-50mm adjustable length, 10mm rise, 31.8mm barbore, 7075 alloy, 2x6mm spacer
Handlebar
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
-
Grips
Ergon GDH Team black
Seatpost
Onoff S3 DH Alloy, diameter 31.6mm, length 300mm
-
Saddle
Ergon SM10 DH Black
Front brake
Shimano Saint M820, 4-piston caliper, RT86 203mm 2-piece IS 6 bolts rotor with ICE technology, resin pads with cooler
-
Rear brake
Shimano Saint M820, 4-piston caliper, RT86 203mm 2-piece IS 6 bolts rotor with ICE technology, resin pads with cooler
Brake lever
Shimano Saint, ergonomic antiskid lever with servo wave, free stroke and tool less reach adjust
-
Rims
e*thirteen Grappler Race DH, IW29 29" Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 32 spokes
Spokes
e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
-
Front hub
e*thirteen Boost 20x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
Rear hub
e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, HG freehub
-
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
Rear tire
Maxxis Dissector 27''5x2.4 WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
-
Crankset
Shimano Saint M825 Hollowtech II, reinforced steel axle, 165mm
Rings
36T, aluminum, BCD 104
-
Bottom bracket
Shimano 83mm
Chain
Shimano HG95, 10s
-
Front derrailleur
e*Thirteen Vario Compact Upper Slider ,Alloy backplate ,DMB (Direct mount Bashguard) Lower Slider 34-36t, ISCG 05 adjustable upper slider
Rear derrailleur
Shimano Saint RD-M820-SS, 10s, Shadow+, short cage
-
Shift levers
Shimano Saint SL-M820 10s, low friction multi bearing, instant release, multi release, 2-way release
Casette
Shimano CS-HG500-10, 11-25T, 10s
-
Derailleur hanger
Mondraker M068
Others
*Geometry kit included: +-1º / +-2º headset cups
Frame sizeS M L A Seattube length 400 mm 400 mm 400 mm 400 mm B Toptube length 576 mm 596 mm 621 mm 646 mm C Bottom bracket drop -5 mm -5 mm -5 mm -15 mm D Bottom bracket height 350 mm 350 mm 350 mm 350 mm E Chainstay length 450 mm 450 mm 450 mm 450 mm F Seat tube angle 69° 69° 69° 69° G Effective seattube angle 77° 77° 77° 77° H Headtube angle 63.5° 63,5º 63,5º 63,5º I Fork Offset 58 mm 58 mm 58 mm 58 mm J Wheelbase 1256 mm 1270 mm 1301 mm 1326 mm K Headtube length 112 mm 112 mm 112 mm 112 mm L Reach 430 mm 450 mm 475 mm 500 mm M Stack 632 mm 632 mm 632 mm 632 mm
