£3,499 FOR A BIKE WITH THIS SPEC! Get raw! During the R&D phase of the new Haro Greer Alloy full-suspension MTB, the response was clear: a production version of the raw aluminum frame should be launched. Our answer: the limited edition Greer Raw LTD 1 and LTD 2. The anodized, rough raw finish on the polished surface with etched details looks clean, fast, and ready to rip. Both models come in premium builds with Fox suspension.
The Greer Alloy Raw LTD 1 & Greer Alloy Raw LTD 2 variants are now available in limited quantities.
FEATURES
- Haro Greer alloy full-suspension frame with raw anodized finish, 1-1/8" - 1-1/5" Tapered Head Tube, 148mm Boost OLD, UDH Derailleur Hanger
- Fox Float X2 Performance Elite shock, 160mm travel
- Fox Float 38 Performance Elite with Grip X, 170mm travel
- SRAM GX Eagle Transmission Wireless drivetrain
- DT Swiss M 1900 wheel set
- Vittoria Mazza 2.4", enduro G2.0 front & Vittoria Martello 2.4" enduro G2.0 rear tires
- TRP DH-R EVO 4-piston hydraulic disc brakes with 203mm rotors, front & rear
- Race Face Turbine bars & stem
- Kind Shock LEV Integra dropper post, size specific
- Includes tubeless valves and sealant
| FRAMESET | |
|---|---|
| Frame | Haro Greer alloy full-suspension frame with raw anodized finish, 1-1/8" - 1-1/5" tapered head tube, 148mm Boost OLD, UDH derailleur hanger |
| Fork | Fox Float 38 Performance Elite with Grip X, 170mm travel |
| Frame Shock | Fox Float X2 Performance Elite, 160mm travel |
| Colors | Raw |
| Weight | 38.1 lbs 17.26 kg, (L) |
| DRIVETRAIN | |
| Cranks | SRAM GX Eagle T-Type 165mm, Q174, CL:55 |
| Pedals | N/A |
| Chain | SRAM GX Eagle T-Type 12-speed |
| Bottom Bracket | SRAM DUB BSA 73mm wide |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM GX AXS T-Type, 12-speed |
| Derailleur Shifter | SRAM AXS POD right bridge |
| Freewheel/Cassette | SRAM AXS 1275 T-Type, 10-52T |
| WHEELS | |
| Tires | Front: Vittoria Mazza 2.4", enduro G2.0 120TPI / Rear: Vittoria Martello 2.4" enduro G2.0 120TPI |
| Wheels/Rims | DT SWISS E 1900 Spline wheel set |
| BRAKING SYSTEM | |
| Brakes | TRP DH-R EVO 4-piston hydraulic disc with 2.3mm thick, 203mm rotors, front & rear |
| Brake Levers | TRP DH-R EVO |
| OTHER COMPONENTS | |
| Grips/Tape | WTB Wavelength 130mm lock-on |
| Handlebar | Race Face MY25 Turbine, 35mm OD, 40mm rise, 800mm wide |
| Stem | Race Face Turbine R, 35mm ID, 40mm reach |
| Headset | FSA ORBIT 1.5E ZS/ NO.57E tapered, 44/56mm head tube |
| Saddle | WTB Volt Medium PU leather, flex-tuned, chromoly rails, with ABR corners |
| Seat Post | Kind Shock LEV Integra dropper, 34.9mm OD, Sizes: Small 150mm, Medium 170mm, Large 200mm, X-Large 200mm |
| Seat Clamp | 3D Forged 6061 aluminum 38.9mm ID |
| Extras | Includes tubeless valves and sealant |
| SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seat Tube (C-T) | 361mm | 410mm | 448mm | 473mm |
| Top Tube (Effective) | 561mm | 593mm | 620mm | 646mm |
| Head Tube Angle | 63.8° | 63.8° | 63.8° | 63.8° |
| Seat Tube Angle | 78° | 78° | 78° | 78° |
| Chainstay Length | 435mm | 435mm | 435mm | 435mm |
| BB Drop | 30mm | 30mm | 30mm | 30mm |
| Wheelbase | 1210mm | 1244mm | 1273mm | 1303mm |
| Head Tube Length | 90mm | 100mm | 110mm | 120mm |
| Standover | 697mm | 701mm | 714mm | 714mm |
| Stack Height | 615mm | 624mm | 633mm | 642mm |
| Reach | 430mm | 460mm | 485mm | 510mm |
| Axle to Crown | 584mm | 584mm | 584mm | 584mm |
| Fork Offset | 44mm | 44mm | 44mm | 44mm |
| Stem Length | ||||
| Bar Width | ||||
| Crank Length | ||||
| Wheel Size | 29F / 27.5R | 29F / 27.5R | 29F / 27.5R | 29F / 27.5R |
